Gen 2 - 4G Cellular Gateway


  • Part #:RFR-0538-2
  • Weight:7 oz
  • Dimensions:5.004 x 3.8 x 1.51 in.
  • Availability: Inquire

Price: $404.25
Price: $553.82


Description

The Scigiene GEN 2 4G Cellular Gateway allows you to control GEN 2 Wireless Sensor settings without additional IT infrastructure. All you need is a power source to monitor your environment and equipment using Scigiene’s industry-leading wireless devices. The 4G Cellular Gateway will communicate with Scigiene Sensors and Scigiene Premiere to deliver data and send alerts about various machine, equipment, or area conditions.

The 4G Cellular Gateway connects GEN 2 Sensors to Scigiene Premiere using 4G LTE CAT-M1/NB2 or 4G Long-Term Evolution Category M1/Narrowband-Internet of Things (NB-IoT) 2 cellular technology. The gateway is equipped with a 24-hour backup battery. GEN 2 Sensors will continue to communicate with Scigiene Premiere via cellular transmission in the event of a power outage.

Additionally, the gateway comes with an RJ-45 Ethernet jack (future capability) for local device configuration. The 4G Cellular Gateway is ideal for applications without a wired Internet connection or where infrastructure is dedicated to other resources.

Features:

  • 32,000 sensor message memory
  • Over-the-air (OTA) updates (future-proof)
  • True plug and play, no hassles for Internet configuration setup
  • No PC required for operation
  • Local status LEDs with transmission and online status indicators
  • AC power supply
  • RJ-45 10/100BASE-TX Ethernet jack for configuration (future capability)

Specifications:

Cellular

Cellular Technology

LTE CAT-M1 / NB2 module for global use in bands 1,2,3,4,5,8,12,13,18,19,20,25,26,27,28,66,71,85

SIM Card Compatibility

Mini-SIM (3FF) 15 mm x 12 mm x 0.76 mm

Antenna Type

Connector: SMA / Gain: 4.0 dBi

Ethernet

Hardware

IEEE 802.3 10/100BASE-TX compatible controller

Operation

Full- and Half-Duplex

Cross-over Correction

Automatic MDI / MDI-X

Protocols Supported

DHCP, DNS, UDP, TCP, SNTP, MSVR Proprietary

Power

Input Power

5.0 VDC @ 1 A

Battery Backup

Battery Type: Rechargeable Lithium Polymer

Battery Duration: Up to 24 hours

Battery Cycle Life: 500 times

Battery Safety: IEC62133

Environmental

Operating Temperature

+5 to +45°C (41 to 113°F)

Storage Temperature

-20 to +60°C (-4 to 140°F)

Gen 2 Wireless

Transmit Power (EIRP)

50 mW (900 MHz), 25 mW (868 MHz), 10 mW (433 MHz)

Antenna Type

Connector: RP-SMA / Gain: 3.0 dBi (900/868) 2.5dBi (433)

Wireless Range

1,200+ ft. non-line-of-sight*

Security

Encrypt-RFP (256-bit Diffie-Hellman key exchange and AES-128 CBC)
